WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] |
BREAKING
STRENGTH
[N] |
BELT WEIGHT
[kg/m] |
| 16 |
2190 |
/ |
7480 |
0,097 |
| 25 |
3660 |
1830 |
12450 |
0,150 |
| 32 |
4880 |
2440 |
16600 |
0,190 |
| 50 |
8050 |
4025 |
27400 |
0,300 |
| 75 |
12200 |
6100 |
41500 |
0,450 |
| 100 |
16600 |
8300 |
56500 |
0,600 |
| 150 |
25300 |
12600 |
86400 |
0,900 |
|
|
 |
|
 |
|
| Tolerance for belt width |
±0,5 |
| Tolerance for nominal thickness |
±0,30 |
|
|
|
