WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] |
BREAKING
STRENGTH
[N] |
BELT WEIGHT
[kg/m] |
| 25 |
6020 |
3010 |
19630 |
0,270 |
| 32 |
7400 |
3700 |
24160 |
0,350 |
| 50 |
12040 |
6020 |
39270 |
0,550 |
| 75 |
18050 |
9025 |
58900 |
0,800 |
| 100 |
25000 |
12500 |
81560 |
1,100 |
| 150 |
36400 |
18050 |
119000 |
1,600 |
| 200 |
49100 |
24550 |
160500 |
2,13 |
|
|
 |
|
 |
|
| Tolerance for belt width |
±1,0 |
| Tolerance for nominal thickness |
±0,45 |
|
|
|
