WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] |
BREAKING
STRENGTH
[N] |
BELT WEIGHT
[kg/m] |
| 6 |
395 |
/ |
1225 |
0,018 |
| 10 |
630 |
315 |
1960 |
0,030 |
| 16 |
1260 |
630 |
3920 |
0,048 |
| 20 |
1730 |
865 |
5390 |
0,060 |
| 25 |
2050 |
1025 |
6370 |
0,075 |
| 32 |
2680 |
1340 |
8330 |
0,096 |
| 50 |
4255 |
2125 |
13230 |
0,150 |
| 75 |
4890 |
2445 |
18580 |
0.225 |
|
|
 |
|
 |
|
| Tolerance for belt width |
±0,5 |
| Tolerance for nominal thickness |
±0,20 |
|
|
|
