| WIDTH (mm) |
MAX TRACTION LOAD (N) |
BREAKING STRENGTH (N) |
| 25 | 3705 | 14820 |
| 32 | 4880 | 16600 |
| 50 | 7870 | 31490 |
| 75 | 12675 | 48165 |
| 100 | 17060 | 64830 |
| 150 | 28050 | 98180 |
 |
| Tolerances for belt width | ±0,5 |
| Tolerances for nominal thickness | ±0,3 |
|
| Min. number of teeth and outside diameter | Z=15Φ 45.90mm |
| Φ Min. inside idler | Φ 50 |
| Φ Min. outside idler | Φ 100 |
|
