| WIDTH (mm) |
WIDTH (inch) |
MAX TRACTION LOAD (N) |
BREAKING STRENGTH (N) |
| 38.1 | 150 | 3720 | 1170 |
| 50.8 | 200 | 5230 | 16450 |
| 76.2 | 300 | 7450 | 25300 |
| 101.6 | 400 | 10470 | 32900 |
 |
| Tolerances for belt width | ±0,5 |
| Tolerances for nominal thickness | ±0,3 |
|
| Min. number of teeth and outside diameter | Z=14Φ 55.25mm |
| Φ Min. inside idler | Φ 60 |
| Φ Min. outside idler | Φ 60 |
|
