| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
15 |
20 |
25 |
40 |
55 |
85 |
100 |
150 |
| MAX TRACTION LOAD (N) |
|
|
|
6700 |
12300 |
16750 |
25800 |
33500 |
51000 |
| BELT WEIGHT (gr./mt) |
118 |
177 |
236 |
295 |
380 |
590 |
880 |
1175 |
1770 |
| WIDTH TOLERANCE [mm] |
±1,0 |
| THICKNESS TOLERANCE [mm] |
±0,4 |
 |
| • minimum no of teeth pulley accepted |
z |
32 |
|
| • minimum diameter for inside idler |
- | |
|
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
40 |
|
| • minimum diameter for outside idler |
Ø |
250 |
mm |
|
|
