| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
|
10 |
15 |
20 |
30 |
50 |
85 |
100 |
150 |
| MAX TRACTION LOAD (N) |
|
|
2000 |
3020 |
4480 |
7100 |
12650 |
13800 |
23800 |
| BELT WEIGHT (gr./mt) |
|
66 |
105 |
164 |
197 |
328 |
490 |
656 |
990 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,3 |
 |
| • minimum no of teeth pulley accepted |
z |
18 |
|
| • minimum diameter for inside idler |
- | |
|
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
25 |
|
| • minimum diameter for outside idler |
Ø |
100 |
mm |
|
|
