HF |
HP |
KEVLAR |
| MIN. NUMBER OF TEETH |
16 |
20 |
16 |
| OUTSIDE DIAMETER |
40.74 |
50.93 |
40.74 |
| MIN. INSIDE IDLER |
40 |
50 |
40 |
| MIN. OUTSIDE IDLER |
60 |
100 |
60 |
|
|
| HF |
| WIDTH (mm) |
10 |
12 |
15 |
20 |
30 |
50 |
85 |
| WIDTH TOLERANCE (mm) |
±0.5 |
| THICKNESS TOLERANCE (mm) |
±0.25 |
| MAX TRACTION LOAD (N) |
750 |
940 |
1225 |
1700 |
2650 |
4550 |
8290 |
| BREAKING STRENGTH (N) |
3000 |
3750 |
4900 |
6800 |
10600 |
18200 |
31500 |
|
|
| HP |
| WIDTH (mm) |
10 |
12 |
15 |
20 |
30 |
50 |
85 |
| WIDTH TOLERANCE (mm) |
±0.5 |
| THICKNESS TOLERANCE (mm) |
±0.25 |
| MAX TRACTION LOAD (N) |
1300 |
1520 |
1950 |
2800 |
4325 |
7350 |
13240 |
| BREAKING STRENGTH (N) |
5200 |
6070 |
7800 |
11200 |
17300 |
29400 |
51000 |
|
|
| KEVLAR |
| WIDTH (mm) |
10 |
12 |
15 |
20 |
25 |
30 |
50 |
85 |
| WIDTH TOLERANCE (mm) |
±0.5 |
| THICKNESS TOLERANCE (mm) |
±0.25 |
| MAX TRACTION LOAD (N) |
1125 |
1310 |
1680 |
2430 |
3000 |
3750 |
6375 |
11640 |
| BREAKING STRENGTH (N) |
4500 |
5250 |
6750 |
9750 |
12000 |
15000 |
25500 |
44250 |
|
