WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] |
BREAKING
STRENGTH
[N] |
BELT WEIGHT
[kg/m] |
| 25 |
3660 |
1830 |
12460 |
0,200 |
| 32 |
4880 |
2440 |
16620 |
0,250 |
| 50 |
8050 |
4025 |
27430 |
0,400 |
| 75 |
12200 |
6100 |
41560 |
0,600 |
| 100 |
16100 |
8050 |
54860 |
0,800 |
| 150 |
25300 |
12650 |
86400 |
1,2 |
|
|
 |
|
 |
|
| Tolerance for belt width |
±1.0 |
| Tolerance for nominal thickness |
±0.45 |
|
|
|
