| WIDTH (mm) |
MAX TRACTION LOAD (N) |
BREAKING STRENGTH (N) |
| 32 | 3370 | 10600 |
| 50 | 5230 | 16450 |
| 75 | 8260 | 25960 |
| 100 | 10470 | 32900 |
 |
| Tolerances for belt width | ±0,5 |
| Tolerances for nominal thickness | ±0,3 |
|
| Min. number of teeth and outside diameter | Z=10Φ 15.05 mm |
| Φ Min. inside idler | Φ 40 |
| Φ Min. outside idler | Φ 60 |
|
