| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
16 |
25 |
32 |
50 |
75 |
100 |
150 |
| MAX TRACTION LOAD (N) |
|
|
5620 |
7150 |
11250 |
16100 |
22500 |
33200 |
| BELT WEIGHT (gr./mt) |
108 |
173 |
270 |
350 |
500 |
750 |
1000 |
1420 |
| WIDTH TOLERANCE [mm] |
±1,0 |
| THICKNESS TOLERANCE [mm] |
±0,45 |
 |
| • minimum no of teeth pulley accepted |
z |
18 |
|
| • minimum diameter for inside idler |
Ø |
120 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
25 |
|
| • minimum diameter for outside idler |
Ø |
180 |
mm |
|
|
